HIGH STRENGTH AND ABRASION RESISTANT WEAR PLATES

Adsteel is pleased to offer an extensive range of high strength and abrasion resistant steel plates on mill order basis from ISO 9000 accredited still mills in Korea and China. Production processes are B.O.F. , E.A.F.

Typical applications include the following –

Transport – trailers , cranes , dump truck trays for iron ore / coal etc.

Mining – Hoppers , conveyors , excavation buckets , loaders, drag lines.

TYPICAL GRADES AVAILABLE INCLUDE THE FOLLOWING STANDARDS

• S460 Q / QL / QL1
• S690 Q / QL / QL1
• S960 Q / QL
• ASTM A514 Gr B/E/F/H/Q
• NM 360 , 400 , 450 , 500 , 550 (similar to Bisalloy / Hardox / Abrex / Sumihard)
• A wide range of steel specifications can be produced to meet European , American or Australian standards.

Thickness Range: 5 mm up to 200 mm

Width capacity: 4300 mm maximum

Supply condition: Bare steel or shotblasted and primered. In line ultrasonic testing to European Standards.

Please contact us for further information.
